Laser sensor RD700 Digital
- Solid construction
- Readable display
Description
Nivel System RD700 Digital
Digital sensor with numeric elevation
- Universality – cooperation with a laser beam: red and green
- Wide detection range of the laser beam through a 90 mm ribbon detector
- High accuracy work (changeable: 1 mm, 2 mm, 5 mm, 10 mm)
- Detector calculates and displays the specific value of the difference level in millimeters [mm]
- Everything in sight- a large, clear LCD display (second display on the back of the sensor), additional LED display to read from far distances (eg. when reading from the cab of the machine)
- Audible differences in height (different volume levels)
- Automatic shut-off after 30 minutes of no response
- Tight fit on the staff of the laser using the handle (supplied with the sensor)
- High resistance to the action of water and dust, confirmed class IP67
Equipment
Specification
| Capture height | 90 mm |
| Reception angle | ±45° |
| Detectable spectrum | 450nm – 800nm (red and green) |
| Accuracy mode (mm) | 1/ 2 / 5 / 10 mm |
| Protection class | IP67 |
| Automatic shutoff | after 30 min. |
| Power supply | 1 x AA |
| Operating temperature | -20°C – +50°C |
| Dimensions | 135 x 69 x 25 mm |
| Weight | 0,19 kg |
